RH & RE Overdrive Planet Kit 5P (BBK-R)


Mfg Retail: $139.95
Cost From Us: $115.88
You Save: $24.07
In Stock
Our Part #: 12580BBK-R
Manufacturer: Cascade Product
free shipping
Overdrive Planet Kit 15 Degree Recon Update
Cascade Custom Assembled 5 Pinion HD Overdrive Planet Kit

Cascade House Product - Used & Reconditioned As We Determine With Stock On Hand
5 Pinion Planet, 15 Degree Overdrive Sun Gear, Matching Pitch Overdrive Ring Gear
Easy To Identify As The Overdrive Ring Gear Will Always Have An ID Groove On The Outside Of The Casting !

Fits The Majority Of Rear Wheel Drive Dodge & Jeep Trucks
1988 To 2004

Fits ALL Below Automatic Transmission Applications :

A500 / A-500 / 500 / 42RH / 42RE / 42-RE / 44RE / 44-RE
A518 / A-518 / 518 / 46RH / 46-RH / 46RE / 46-RE
A618 / A-618 / 618 / 47RH / 47-RH / 47RE / 47-RE

This Kit Will Update ALL RH & RE Of These Trucks On The Road Today !
( Excluding 48RE's )   Package Is Light Duty For 48RE Dodge Truck Applications

Fits 2WD & 4WD Trucks Alike !

Specific Contents Of This Package:

Overdrive Planet, 5 Pinion Carrier Housing - Reconditioned / Remanufactured
Overdrive Ring Gear 15 Degree ( Anulus )  - Mint Used
Overdrive Sun Gear, Top Hat Bushing ( Inner Gear ) - Reconditioned Used

Sun Gear May Have Smooth Top Or Top Hat Style Bushing Design, These Will Interchange With No Issues

Ideal Package If Your Overdrive Planet Section Is Roasted, and/or Entirely Destroyed.
This kit is the updated 1994 up late 15 degree pitch as mentioned.
Five (5) pinion gears on the planetary spreads the load evenly over the carrier.
The only kit stronger than this would be the 6 pinion package, see our part # 12580BCK

We Reserve The Right To Change Or Add A New Part To The Kit As Stock Supply On Hand May Vary.

This Package Would Be Normal Stock To Find Installed In A 1996-2003 Dodge Ram Cummins Diesel
This Would Be A Great Upgrade For All Smaller Engine Models From Their Stock 4 Pinion Set.
In 1988-1994 trucks normally contain the early 22 degree pitch planets
They found the 15 degree was better to transfer the torque and not loose so much power.
The early gears simply absorbed the power and tended to pit and wear out and/or fail much faster

Additional Images To Be Added Soon

Photo Shown Is Actual Product To Be Shipped With This Purchase

Our Part #       12580BBK-R
